Voltage: 12 volts DC
Dimensions: 5” x 5” x 1 3/8”
(127 mm x 127 mm x 35 mm)
INSTRUCTIONS:
1- Deter
mine the location of the control.
The wall control must be installed in a central location on the main floor.
Typical locations for these controls are kitchen, main hallways and family room.
2- Remove the button(s) and the cover plate of the control.
22
8.1 D
IMENSIONS AND
S
PECIFICATIONS
(M
AIN
C
ONTROLS
)
8.0
Installation of the Controls
8.2 I
NSTALLATION OF THE
M
AIN
C
ONTROL
(E
CONOMY AND
V
ALUE
)
1
3
/
8
"
(35 mm)
5" (127 mm)
VC0016
5" (127 mm)
FRONT VIEW
SIDE VIEW
VC0026
VALUE
ECONOMY
CAUTION
Never install more than one main control per unit.
