Table of Contents (cont’d)
About this Manual
8.0 INSTALLATION OF THE CONTROLS......................................................................22
8.1 Dimensions and Specifications................................................................22
8.2 Installation of the Main Control..........................................................22-23
8.3 Electrical Connection to Optional Controls ..............................................24
8.4 Electrical Connection to the Furnace ......................................................24
9.0 W
IRING DIAGRAM ............................................................................................25
10.0 AIR FLOW BALANCING ................................................................................26-27
11.0 OVERALL VERIFICATION ....................................................................................28
11.1 Main Controls..........................................................................................28
11.2 Optional Control ......................................................................................28
12.0 MAINTENANCE / INSTRUCTIONS FOR USER........................................................29
13.0 TROUBLESHOOTING......................................................................................30-31
14.0 R
EFERENCES ....................................................................................................32
This manual uses the following symbols to emphasize particular information:
NOTE: Indicates supplementary information needed to fully complete an instruction.
WARNING
Identifies an instruction which, if not followed, might cause serious personal injuries
including possibility of death.
CAUTION
Denotes an instruction which, if not followed, may severely damage the unit and/or
its components.
