Instrument Overview page 13
User Guide for Jess
NOTES:
Remove the lid and seal from the plate immediately before inserting into the instrument.
When inserting the sample plate, make sure the plate is firmly seated and level in the tray. Plates that
aren’t level can interfere with the movement of the plate holder.
Rear Panel
Located on Jess’s rear panel is the power entry, power switch and the network connection port.
• System Power - The main system power components consist of the power switch and power input.
!WARNING!
Only use the power supply cord provided with Jess. If the cord is damaged, please contact
ProteinSimple Technical Support toll-free in the US and Canada at 1-888-607-9692 (option 3).
!WARNING!
You can't replace any parts except the power entry fuse.
!WARNING! SHOCK HAZARD
Disconnect the power cord from the power input to disconnect power to the instrument.
• Connect to PC - A 10/100/BASE-T Ethernet (RJ-45 connector) is used to connect Jess to a computer.
