3-LITE END ASSEMBLY INSTALLATION PACK CONTENTS
NOTE: The individual installation packs are labeled and numbered. Please refer to the chart below for the
appropriate pack contents and for the installation location.
3
⁄8" Hole Plugs (Color Matched), Part #: S-HG-698-CC
#8 x 3" Phillips Square Screws, Part #: S-HS-350-00
#2 Phillips Square Combo Bit, Part #: S-ST-347
Foam Plugs, Part #: S-HG-521-01
#8 x 1" Phillips Pan Head Screws, Part #: S-HS-345-00
Head Weatherstrip Block, Part #: S-HG-524-13
#8 x 1
1
⁄4" Phillips Pan Head Screws, Part #: S-HS-342-13
Sash Stop (Bumper), Part #: S-HG-532-13
#8 x 1
1
⁄4" Phillips Pan Head Screws, Part #: S-HS-342-13
(1) Installation
Pack #2
S-DH-020S-CC
(Jambs & Header)
(2) Installation
Pack #3
S-DH-023S-CC
(Fixed Sashes)
(2) Installation
Pack #4
S-DH-024S
(Header Block)
(1) Installation
Pack #5
S-DH-025S
(Header Bumper)
The individual installation packs are labeled, numbered
and are all packed inside one main bag. Open up the
main parts bag and refer to the appropriate pack contents
for each installation location referenced below.
3-Lite End Active
Installation Pack
S-DH-042S-CC
(16)
(16)
(1)
(4)
(4)
(1)
(2)
(1)
(2)
(1)
#8 x 2” Phillips Square Stainless Steel Screws,
Part #: S-HS-344-00
(2) Installation
Pack #1
S-HS-344S-CC
(Frame Assembly)
(10)
Screw Caps, Part #: S-HS-311-CC
(4)
