4
(1) Installation
Pack #10
S-DH-010S
(Screen)
Screen Wheel Brackets,
Part #: S-HG-366P-00 (Right Hand)
Part #: S-HG-367P-00 (Left Hand)
#6-32 x
7
⁄8" Phillips Flat Head Screws, Part #: S-HS-360-00
(1)
(1)
(2)
AccuVent Bolt Plate (Color Matched), Part #: S-HG-573-CC
#8 x 1 Combo Vinyl Hold (Color Matched),
Part #: S-HS-340-CC
(1)
(2)
(1) AccuVent
™
Bolt Plate Kit
S-HG-573S-CC
(Standard on Endure,
Optional on Aspect)
Active Sash Secondary Lock (Foot Lock) (Color Matched),
Part #: S-HG-353-CC
#8 x
3
⁄4” Phillips Oval Head Screws (Color Matched),
Part #: S-HS-414-CC
3-Lite Shims, Part #: S-HG-542-13
(1) Installation
Pack #6
S-DH-026S-CC
(Standard on Aspect,
Optional on Endure)
(1) Installation
Pack #14
S-HG-54S-13
(Sill of Fixed Sash)
(1)
(4)
(4)
ASPECT
™
AND ENDURE
™
3-LITE END ASSEMBLY INSTALLATION PACK CONTENTS
NOTE: The individual installation packs are labeled and numbered. Please refer to the chart below for the
appropriate pack contents and for the installation location.
(1) Installation
Pack #8
S-DH-028S-CC
(Screen Mullion)
NOT USED with
END ACTIVE
Screw Cap Cover (Color Matched), Part #: S-HG-534-CC
#8 x 1" Phillips Flat Head Screws, Part#: S-HS-351-00
(5)
(5)
