Proxim Orinoco AP-8100 Hardware Installation Guide

Hardware Specifications
ORiNOCO
®
802.11n & 802.11ac Access Points - Hardware Installation Guide 32
Receive Sensitivity
*MCS refers to Modulation Coding Scheme.
Local Configuration
Support
RS-232 Serial port, DB9 Female
Remote Configuration
Support
Telnet and SSH, Web GUI (http) and SSL (https), TFTP
SNMP v1, v2c and v3
SNMP trap and Syslog
PVES (ProximVision ES Network Management Systems)
Message Authentication 802.11i AES message authentication with 128 bit keys
TKIP with 128 bit Michael Message Integrity Check
Intrusion detection Detect MIC intrusion attacks
Dimensions
(L x W x H)
11.1 x 6.85 x 1.89 in. (282 x 174 x 48 mm)
: These dimensions exclude the antennas.
Weight AP-800 - 0.7 Kgs (1.54 lbs)
AP-8000 - 0.75 Kgs (1.65 lbs)
Environmental Operating Temperatures:
0 to 55ºC
5 to 95 percent (non-condensing)
Storage Temperature:
-20º to 75ºC
MTBF 43,800 hrs
Warranty One year parts/labor
11b 11a/g 11n
Data
Rate
(Mbps)
Receive
Sensitivity
(2.4-5Ghz)
Data
Rate
(Mbps)
Receive
Sensitivity
(2.4-5Ghz)
Data
Rate
(MCS*)
Receive
Sensitivity
(2.4-5Ghz)
1 -94 6 -96 MCS 0 -90
11 -91 36 -87 MCS 8 -91
- - 48 -83 MCS 10 -83
- - 54 -82 MCS 15 -72
