Proxim Orinoco AP-8100 Hardware Installation Guide

Hardware Specifications
ORiNOCO
®
802.11n & 802.11ac Access Points - Hardware Installation Guide 34
3.1.1.2 Range Extender Antenna (REA) Specifications
Radio Patterns
Feature Electrical Specifications
Frequency Range 2400 MHz - 2500 MHz 4900 MHz – 5875 MHz
Peak Gain 3 dBi 6 dBi
VSWR 2.0 : 1 Max 2.5 : 1 Max
Polarization Linear, Vertical
HPBW/Horizontal 360
o
360
o
Feature Environmental and Mechanical Specification
