Hardware Specifications
ORiNOCO
®
802.11n & 802.11ac Access Points - Hardware Installation Guide 39
3.2.1 Antenna Specifications
Feature Specification
Frequency Range 2.4 GHz - 2.5 GHz 5.1 GHz – 5.825 GHz
Peak Gain 3.0 dBi 4.0 dBi
VSWR 2.0 : 1 2.0 : 1
Isolation (db) > 20 > 15
Impedence 50 Ohms
Max.Power 1 Watts
Weight 11 g
Connector IPEX
Cable Length (mm) TBD
Dimension (mm) 90.4 x 86 x 10
