ORiNOCO
®
802.11n Access Points - Software Management Guide 43
Channel Blacklist Information
A channel is blacklisted when a RADAR is detected in it. The Channel Blacklist Information table lists all the blacklisted
channels, which includes the information tabulated below.
5.4.1.2 11n Properties
To configure the 11n properties of the wireless interface, navigate to CONFIGURATION > Wireless > Interface 1 > 11n
Properties. The Wireless Interface 1 11n Properties screen appears.
Figure 5-10 Wireless Interface 1 11n Properties
Tabulated below are the ‘11n Properties’ and the method to configure the configurable parameters:
Parameter Description
Channel Number Specifies the channel number of the blacklisted channel.
Reason Specifies the reason for blacklisting a channel.
Time Elapsed Specifies the time period, during which a channel is not operational.
Parameter Description
11n AMPDU
(Aggregated MAC
Protocol Data Unit)
This parameter enables the user to aggregate several MAC frames into a single large frame
to achieve high throughput.
By default, AMPDU status is enabled. To disable, select Disable from the drop down menu.
AMPDU Max Num
Frames
Specifies the maximum number of frames that are aggregated and transmitted as a single
Protocol Service Data Unit (PSDU) by the physical layer.
By default, the AMPDU Max Num Frames is 64. To configure, enter a value ranging from 2
to 64 frames.
AMPDU Max
FrameSize
Specifies the maximum AMPDU frame size (in bytes) that can be transmitted.
By default, the AMPDU Max FrameSize is 65535 bytes. To configure, enter the frame size
ranging from 1k to 64k bytes.
