ORiNOCO
®
802.11n Access Points - Software Management Guide 94
6.2 File Management
The File Management tab enables you to upgrade the firmware and configuration files onto the device, and retrieve
configuration and log files from the device through Hypertext Transfer Protocol (HTTP) and Trivial File Transfer Protocol (TFTP).
• HTTP file transfer can be performed with or without SSL enabled. HTTP file transfer with SSL requires enabling Secure
Management and Secure Socket Layer. HTTP file transfer by using SSL may take extra time.
• A TFTP server must be running and configured to point in the desired directory path to copy the retrieved file.
6.2.1 Update Firmware
6.2.1.1 Update Firmware by Using HTTP
To update the firmware by using HTTP, follow the following steps:
1. Navigate to MANAGEMENT > File Management > Update Firmware > HTTP. The configuration screen appears:
Figure 6-4 Update Firmware by using HTTP
2. In the HTTP screen, click Browse to select the updated firmware file from the desired location.
: The file name should not contain any spaces or special characters.
3. Click Update & Reboot, for the device to get uploaded with new firmware and reboot automatically.
:
• Update & Reboot is applicable only to AP-8100.
• For AP-800 and AP-8000, click Update to load the firmware on to the device and then click Reboot to reboot
the device.
6.2.1.2 Update Firmware by Using TFTP
To update the firmware by using TFTP, follow the following steps:
1. Navigate to MANAGEMENT > File Management > Update Firmware > TFTP. The configuration screen appears:
Allowed Operational
Modes of Radio 2
Specifies the operational modes allowed on the wireless interface (radio) 2.
MAC Address of the
Device
Specifies the MAC address of the device.
