Proxxon CU 4 - CNC Control Unit CU 4 with Control Elements

15
Operating display
On-off switch
5. CNC control unit CU 4 with control elements
Fig. 2: Front
Fig. 3: Rear
Ports for connecting the
step motor plugs
DB 25 connec-
tion for control
computer
Switched power sock-
ets for connecting the
machine tool
Mains cable
Emergency stop
switch
