7. Scope of delivery
Note: Please check the control unit and the connection cables for damage immediately after
receipt! If the items in question are not in perfect condition, immediately contact the dealer from
which you purchased them!
1 unit CNC control unit CU 4
1 unit. Manual
8. Technical data
Voltage supply: 110-230 V (switchable), 50/60 Hz
Power input: max. 2700 Watt
(Power unit: 200 Watt
Sockets for connecting machinery: max. 2500 W)
230 V sockets (2 units), parallel, relay-switchable, max. 2500 W
Power amplifiers: 4 units, 48 V, 2A
Suitable for step motors of NEMA sizes 17, 23 and 24, 1600 steps/revolution
9. Assignment of the Sub-D 9 sockets
