3.2 POSITIONING THE APPLIANCE
For a safe and quiet operation, the furnace must be levelled in both directions. Give each “U” shape track an equal
support so that the weight is evenly distributed.
3.3 PIPE CONNECTOR AND DAMPER
The pipe connecting the furnace to the chimney must be as short as possible. If a deviation is required, the use of 45
o
elbows is highly recommended for a better evacuation of the smoke in the chimney of the wood burning furnace. The
barometric damper provided with the appliance must be installed on the oil unit evacuation pipe, approximately 24
"
from the flue outlet of the unit.
TYPE OF FURNACE (UH) OIL BURNING UNIT FLUE
PIPE DIAMETER
PSG/ UH-MAX CADDY
5”
