Chapter 2: Getting Started
Inserting And Removing A Compact Flash Card
28
Psion Teklogix NETBOOK PRO User Manual
To insert a card:
• Push the MMC or SD into the slot until it clicks. It will then bounce
outward slightly.
Note: Always insert the MMC or SD card with the contacts first and the notch to
the right.
To remove a card:
• Push the edge of the card inwards. It will click, and then bounce out. The
end may then be grasped. Pull the card outward to remove it.
Store your MMC or SD card safely.
2.6.2 Inserting And Removing A Compact Flash Card
The CF slot is located on the left-hand side of the NETBOOK PRO (see Figure 2.18).
Figure 2.18 Compact Flash Slot Location
CF cards are keyed so that they may not be inserted incorrectly. When a memory
card is inserted, a folder for it appears in the Windows Explorer file browser.
To insert a CF card:
• Push the Compact Flash card into the card slot on the left-hand side of the
NETBOOK PRO.
Eject Button
Compact Flash Card Slot
