In addition to the telnet command line interface the Ethernet port also provides remote access to the
ptf 3207A’s web interface. To connect to the web interface:
Find the Ethernet parameter settings as described in the section " Configuring Ethernet
Settings " above
Open a standard web browser (Internet Explorer, Firefox etc.)
In the address bar enter the ptf 3207A's IP address as follows:
http://192.168.0.23/
This will bring up the web browser entry screen. Selected the required module, usually A or B(if
fitted), or C (if fitted).
This will bring up the login screen. Enter the password, (ptf_pwd) and click on submit.
Tip: Although the login page may have an entry in the password field, it is best to re-enter the
password to make sure it is correct.
User name is automatically populated e.g. Module A
