The front deflector must be used with front and lateral wheel accesso-
rie (in mower/shredder mode).
Obligatorys gloves
Max. height. = 85 mm
Min. height = 59 mm
C1
C2
C3
Grass blade
For assembly and the adjust of
height see C1 and C2.
C4
Clearing blade
For assembly and the adjust of
height see C1 and C2.
C5
Tray with chain for the very big clearing
For assembly and the adjust of height see C1 and C2.
C6
Mower shredder option
See manual 25478
C7
D
7
D1
PETROL
2,3 L
3/$0.0+$ #%0$$
Petrol capacity
HONDA GXV 340 K2
D2
Éloigner pieds et mains, lame rotative
risque de sectionnement
Operating speed
control
Accelerator
Circuit-breaker lever
Blade clutch handle
Forward clutch lever
Reverse clutch
1
2
3
4
1 -
Disconnect the sparkplug before any maintenance or
repair work.
2 - Lame rotative attention aux projections.
3 - Read the user's manual.
4-Keep safety distances.
3 2 1
Recommended oil
k
see the motor manual
Oil capacity
1,1 L
HONDA GXV 340 K2
