PAGE 27
I1017-2-D & I1017-3-D
245 REV.110110
INSTALLATION DIMENSIONS
E
FGDCA
HJKM
RS
B
Dimensions in inches
(Dimensions in millimeters)
DRUM
-1 7.6 14.6 10.0 6.8 15.9 15.6 19.1 17.000 23.8 10.6 8.56 11.000 17.5
(194) (371) 254) (173) (404) (396) (486) (431.80) (604) (269) (217) (279.40) (445)
- 2 9.6 14.6 10.0 6.8 15.9 15.6 19.1 17.000 23.8 10.6 8.56 11.000 17.5
(244) (371) (254) (173) (404) (396) (486) (431.80) (604) (269) (217) (279.40) (445)
- 3 9.6 16.6 1 13.0 6.8 16.9 15.6 22.1 20.000 26.8 10.6 8.56 11.000 17.5
(244) (422) (330) (173) (429) (396) (562) (508.00) (681) (269) (217) (279.40) (445)
- 5 7.6 16.6 10.0 6.8 16.9 15.6 19.1 17.000 23.8 10.6 8.56 11.000 17.5
(194) (422) (254) (173) (429) (396) (486) (431.80) (604) (269) (217) (279.40) (445)
- 6 9.6 16.6 10.0 6.8 16.9 15.6 19.1 17.000 23.8 10.6 8.56 11.000 17.5
(244) (422) (254) (173) (429) (396) (486) (431.80) (604) (269) (217) (279.40) (445)
- 7 7.6 16.6 13.0 6.8 16.9 15.6 22.1 20.000 26.8 10.6 8.56 11.000 17.5
(194) (422) (330) (173) (429) (396) (562) (508.00) (681) (269) (217) (279.40) (445)
- 11 7.6 25.0 12.5 6.9 26.0 20.5 22.1 20.000 26.8 15.5 13.50 11.000 22.5
(194) (635) (318) (175) (660) (521) (562) (508.00) (681) (394) (343) (279.40) (572)
HYDRAULIC MOTORS
MOTOR GEARMOTOR PORT SIZE I L
CODE WIDTH SAE O-RING
- 95 2.50 6.9 6.0
(63.5) (175) (152)
- 96 2.25 6.6 6.0
(57.2) (168) (152)
-97 2.00 6.4 6.0
(50.8) (163) (152)
- 98 1.50 5.9 6.0
(38.1) (150) (152)
- 99 1.00 5.4 6.0
(25.4) (137) (152)
- 114 1.75 6.2 6.0
(44.5) (157) (152)
SAE CODE 61
3000 PSI FLANGE
- 139 2.00 6.4 6.0
(50.8) (163) (152)
- 140 1.75 6.2 6.0
(44.5) (157) (152)
- 141 1.00 5.4 6.0
(25.4) (137) (152)
Dimensions in inches
(Dimensions in millimeters)
COMMERCIAL WM51 GEAR MOTORS
1 5/8 - 12
1 5/16 - 12
1 1/16 - 12
1 5/16 - 12
1 1/4
1
3/4
