PullRite OE Series - #4500 Parts List

21
2.09.21.RH.rev A
ITEM DESCRIPTION PART NO. QTY MATERIAL
1 FIFTH WHEEL PLATE ASSEMBLY 3601 1
2 ROCKER ARM NUT 98150131 1 3/4”-10 Hex Nut Zinc Plated
3 ROCKER ARM 3302 1
4 ROCKER ARM SPRING NUT 98410161 1 5/16”-18 Low Pilot Height Weld Nut
5 ROCKER ARM SPRING 35100001 1
6 CAM ASSEMBLY 4503 1
7 ROCKER ARM SPRING WASHER 98250160 1 5/16” FLAT WASHER
8 ROCKER ARM SPRING LOCK WASHER 98200159 1 5/16” LOCK WASHER
9 ROCKER ARM SPRING BOLT 98010244 1 5/16”-18 X 1” Grade 5 Zinc Plated
10 5/16” ADJUSTMENT BOLT 98010244 4 5/16”-18 X 1” Grade 5 Zinc Plated
11 PASSENGER’S SIDE ADJUSTING WASHER 45070202 2
12 STOP PLATE BOLT 98010219 1 5/8”-11 X 2 1/2” TAP Bolt Zinc GR 5
13 WAY TUBES 29060001 2
14 4500 HITCH BASE 4506 1
15 BAIL PIN 98410529 2
16 BRASS MOUNTING WASHER 15070001 2
17 1/2”-13 SERRATED FLANGE NUT 98150201 4 1/2”-13 Serrated Flange Nut Zinc
18 WAY TUBE CARRIAGE BOLT 98050113 4 1/2”-13 x 3.5” Carriage bolt
19 STOP PLATE 44050101 1
20 STOP PLATE JAM NUT 98150122 2 5/8”-11 Hex Jam Nut
21 FLAT WASHER 98250150 2 1/4” Oversized Flat Washer
22 1/4” BH SOCKET CAP SCREW 98410241 2 1/4-20 X 1/2” BH Socket Cap Screw
23 POST HANDLE 15040601 4
24 FOOT POST CASTLE NUT 98150121 4 1”-14 Slotted Castle Nut
25 DRIVER SIDE POST WASHER 45070101 2
26 OE FOOT POST 44480701 4
27 SPRING PIN 98410524 1 3/8” X 1 3/4” Slot Spring Pin
28 PASSENGER REAR POST ASSEMBLY 450704 1
29 PASSENGER FRONT POST ASSEMBLY 450702 1
30 DRIVER FRONT POST ASSEMBLY 450701 1
31 DRIVER REAR POST ASSEMBLY 450703 1
32 ROLLER 23040002 1
33 COTTER PIN 98410567 1 1/4” X 2” Cotter Pin Zinc Plated
34 ROLLER CASTLE NUT 98150121 1 1”-14 Slotted Castle Nut
35 ROCKER ARM BOLT 98010148 1 3/4-10 X7.5 HCS GR 5
36 LATERAL PIVOT SLEEVE 33020104 1
37 CLEVIS PIN 98410111 2 1/2” X 2” Clevis Pin Zinc Plated
38 HITCH PIN CLIP 98410127 2 ZINC PL #3 Hitch Pin Clip
39 ROCKER ARM LOCK WASHER 98200124 1 3/4” Lock Washer
#4500 PARTS LIST
