PullRite OE Series - Attach Handle to Head Plate

8
2.09.21.RH.rev A
1. Remove the hitch pin clip from the spring post and Insert handle through obround hole.
1
OBROUND
HOLE
HITCH PIN CLIP
SPRING POST
2
2. Detach the spring from the spring post and stretch hook inside handle so it reaches beyond the hole in the handle.
3. Bring the handle and sping down over the spring post and replace the hitch pin clip.
3
HITCH PIN CLIP
SPRING POST
ATTACH HANDLE TO HEAD PLATE
