Pulsar AXION LRF XQ38 User Manual

3
USER MANUAL FOR AXION THERMAL IMAGING SCOPE
ENGLISH
TECHNICAL SPECIFICATIONS
Model AXION LRF XQ38
Sku 77428
Microbolometer
Type uncooled
Resolution, Pixels 384x288
Pixel Pitch, µm 17
Frame Rate, Hz 50
Optical Characteristics
Optical Magnication, x 3.5
Smooth Digital Zoom 3.5-14
Digital Zoom, x 2/4
Lens Focus, mm 38
Focal Ratio, D/F' 1.2
Minimum Focusing Distance, m 3
Eye Relief Diameter, mm 3.5
Angular Field of View (HxV), Degree 9.8x7.4
Linear Field of View, m Per 100 m 17.2
Eyepiece Focusing Range, Diopter +4/-5
Detection Distance for Deer-Sized Objects, (m) 1350
Display
Type AMOLED
Resolution, Pixels 1024x768
Operational Characteristics
Power Supply, V 3-4.2 V
Battery Type APS 5 Li-ion Battery Pack
Capacity 4900 mAh
Nominal Output Voltage DC 3.7 V
External Power Supply 5 V (USB Type-C)
Battery Run Time At T=22 °C, h 7
Degree of Protection, IP Code (IEC60529) IPX7
Operating Temperature Range, °C -25 … +40
Dimensions, mm 167x74x73
Weight (Without Battery), kg 0.38
Characteristics Of The Rangender
Wavelength, nm 905
Measurement Range, m** 1000
Measurement Accuracy, m 1
Built-in Memory 16 GB
* Depends on the characteristics of the object under observation and environmental conditions.
PACKAGE CONTENTS
•
AXION LRF XQ Thermal Imager
•
Carrying case
•
APS 5 rechargeable battery
•
Hand strap
•
2 lock-cover of APS 5 battery
•
Quick User Manual
•
Battery Pack Charger
•
Lens-cleaning cloth
•
Power Adapter
•
Warranty sheet
•
USB Type-C Cable
•
Adaptor for mounting the device on a tripod
Improvements may be made to the design of this product to enhance its user features.
The current version of the User Manual can be found on the website www.pulsar-vision.com
DESCRIPTION
AXION LRF XQ thermal imaging monoculars are designed for use both at night-time and during the day in
adverse weather conditions (fog, smog, rain) to see through obstacles (branches, tall grass, dense bushes, etc.)
hindering target detection.
Unlike night-vision devices based on electron-optical converters, thermal imaging devices do not need an
external light source and are resistant to bright light. AXION LRF XQ thermal imagers are designed for various
applications including hunting, observation, security, terrain orientation, search and rescue operations, etc.
AXION LRF XQ thermal imagers are equipped with a built-in laser rangender with a range of up to 1000 m and
a measurement accuracy of ± 1 m.
FEATURES
•
Microbolometer with a resolution of 384x288 pixels
•
Microbolometer pixel size is 17 microns
•
1024x768 AMOLED display resolution
•
Compact size and light weight
•
Functional and ergonomic design
•
User-friendly interface
•
Eight color modes
•
Three calibration modes: Manual, Semi-Automatic, Automatic
•
Detection distance of up to 1350 m
•
Smooth digital zoom 3.5-14x
•
Four observation modes: Forest, Rocks, Identication, User
•
Integrated laser rangender
•
Display Off function
•
Defective pixel repair function
•
Wide operating temperature range (-25°С to +40°С)
•
Fully waterproof (IPX7 rated)
•
Tripod mount
BATTERY PACK
•
Quick Change Li-Ion Battery Pack APS 5
•
Charging from USB Power Bank
•
USB Power Delivery quick charge
