Page #30 background image
Mode
Observation mode selection
There are four observation modes: Forest (mode for low temperature contrast conditions),
Rocks (mode for high temperature contrast conditions), Identification (high detail mode), and
User (personalized brightness and contrast settings mode).
Option 1:
Press the UP (4) button briefly to switch the observation mode
Option 2:
1.
Press and hold the MENU (3) button to enter the main menu.
2.
Use the UP (4) / DOWN (2) buttons to select the Mode icon.
3.
Press the MENU (3) button briefly to enter the Mode submenu.
4.
Use the UP (4) / DOWN (2) buttons to select one of the modes described below.
5.
Press the MENU (3) button briefly to confirm the selection.
ForestMode.The most suitable mode when searching and observing in the field against a
background of foliage, shrubs and grass. This mode provides a high level of information on
both the observed object and landscape details.
RocksMode.The most suitable mode for observing objects after a sunny day or in urban
environments.
IdentificationMode.The most suitable mode for observation in adverse weather
conditions (fog, mist, rain, snow). It allows the characteristic features of objects to be more
clearly recognized. The increased detail may result in a small graininess of the image.
User Mode.It allows you to configure and save custom brightness and contrast settings,
as well as one of the three other modes (Forest, Rocks, Identification) as the base.
http:////www.youtube.com/embed/Mnt5c8ZP1PA
To see the button operation scheme click here.

Other manuals for Pulsar AXION XQ38

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pulsar AXION XQ38 and is the answer not in the manual?

Pulsar AXION XQ38 Specifications

General IconGeneral
Sensor Resolution384x288
Objective LensF38/1.2
Magnification3.5-14x
Detection Range1350 m
Display TypeAMOLED
Battery LifeUp to 6 hours
Frame Rate50 Hz
Microbolometer resolution384x288
Pixel Pitch17 µm
Built-in video recorder availabilityYes
Format of video / photo files.mp4 / .jpg
Built-in memory16 GB
Degree of protection, IP codeIPX7
Wi-FiYes
Stream VisionYes
SensorMicrobolometer
Digital zoom4x
TypeThermal Imaging
Operating temperature range-25°C to +50°C
Battery typeAPS 5
External power supply5V
Field of View9.8x7.4°
Display Resolution1024x768 pixels
