Page #6 background image
Specifications
XQ38
Model XQ38
SKU 77427
Microbolometer
Type uncooled
Resolution, Pixels 384x288
Pixel Pitch, µm 17
Frame Rate, Hz 50
Optical
Characteristics
Optical Magnification, x 3.5
Smooth Digital Zoom 3.5-14
Digital Zoom, x 2/4
Lens Focus, mm 38
Relative Aperture, D/f' 1.2
Minimum Focus
Distance, m
3
Eye Relief Diameter,
mm
3.5
Angular Field of View
(Horizontal x Vertical),
degree
9.8x7.4
Linear Field of View, m
at 100 m
17.2
Eyepiece Focus
Range, Diopter
+4 / -5
Detection Distance for
Deer-Sized Objects,
m/y
1350/1476
Display
Type AMOLED
Resolution, Pixels 1024x768

Other manuals for Pulsar AXION XQ38

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pulsar AXION XQ38 and is the answer not in the manual?

Pulsar AXION XQ38 Specifications

General IconGeneral
Sensor Resolution384x288
Objective LensF38/1.2
Magnification3.5-14x
Detection Range1350 m
Display TypeAMOLED
Battery LifeUp to 6 hours
Frame Rate50 Hz
Microbolometer resolution384x288
Pixel Pitch17 µm
Built-in video recorder availabilityYes
Format of video / photo files.mp4 / .jpg
Built-in memory16 GB
Degree of protection, IP codeIPX7
Wi-FiYes
Stream VisionYes
SensorMicrobolometer
Digital zoom4x
TypeThermal Imaging
Operating temperature range-25°C to +50°C
Battery typeAPS 5
External power supply5V
Field of View9.8x7.4°
Display Resolution1024x768 pixels
