Pulsar PG2000 User Manual

NO. PART NO. DESCRIPTION Q'TY REMARK
1 DF1800H-33008-A
FRONT COVER,ALTERNATOR
1
2 GBT16674-B8-16
FLANGE BOLT M8*16
4
3 DF1500H-33100-BJ-20302
ALTERNATOR ASSEMBLY
1
4 DF3000H-33120-BJ
ROTOR
1
5 DF1800H-33001-A
CARBON BRUSH COMP.
1
6 DF3800H-33002-A
GROUNDING POST COMP.
1
7 DF1500H-33120-BJ-20302
STATOR
1
8 DF1500H-33005-A
ALTERNATOR END BRACKET
1
9 GBT93-LW-8
PLAIN WASHER
1
10 GBT97-W-8
SPRING WASHER
2
11 DF1500H-33003-A
BOLT M8*190
1
12 DF1800H-33015-B
BOLT M6*110
4
13 GBT16674-B5-12
FLANGE BOLT M5*12
7
14 DF1800H-33006-A-116
ALTERNATOR END COVER
1
15 DF1800H-33011-A
VOLTAGE REGULATOR
1
16 GBT862-CW-5 TOOTH TYPE WASHER 1
17 GBT97-W-5
PLAIN WASHER
1
18 GBT16674-B6-12
BOLT FLANGE M6*12
1
19 GBT97-W-6
PLAIN WASHER
1
20 GBT862-CW-6 TOOTH TYPE WASHER 1
21
DF3000H-31083-A
CONNECTING WIRE, FRAME 1
22
DF3000H-34216-B GROUNDING WIRE
1
38
