PURE Elan E3 User Manual

4
Introduction
Package contents
You’ll find the following items in the box:
• Elan E3
• Power adapter
Note: Retain all packaging after removing your Elan E3 and the accessories from the box. If you decide
to dispose the packaging, please do so according to local regulations.
Front panel controls
Standby: Switch
between on and
standby if powered
by the mains power
adapter or on and off if
powered by batteries.
Digital radio: Press to see
digital radio station list.
FM: Press to enter FM
manual tuning mode.
Source
Press to select digital radio,
FM radio or auxiliary input.
Volume/Select: Turn and press to
select menu options. If listening to
content, turn to adjust the volume.
Presets 1 − 4+: Store up to
20 digital and 20 FM radio
preset stations
Back: Press to return
to the previous menu.
Menu: Press to access
the settings menu.
Downloaded from www.vandenborre.be

PURE Elan E3 Specifications

General

Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, FM
Radio Data System (RDS)	Yes
Preset stations quantity	40
RMS rated power	- W
Number of built-in speakers	1
Display type	TFT
Display diagonal	2.8 \
USB connector type	Micro-USB
Headphone connectivity	3.5 mm
Antenna type	External
MP3 playback	No
Product color	Red, White
Volume control	Rotary
Apple docking compatibility	Not supported
Cables included	DC
Power source	DC/Battery
DC input voltage	6 V
Battery technology	Alkaline
Compatible battery sizes	AA
Number of batteries supported	4

Weight and Dimensions

Depth	53 mm
Width	200 mm
Height	115 mm
