PURE FlexiPump - INSTALLATION: Set-Up Horizontal Wall Mount; INSTALLATION: Set-Up on a Wall

Install your angle wall bracket on a wall. The two small holes on the back piece will be attached to the wall.
Place the FlexiPump nest hole (located on the back) over the thru bolt.
Place the FlexiPump unit into the Nest. Keep one hand on the FlexiPump and attach the pump holder
bracket around the back of the FlexiPump, on the gray cord. Connect the other side of the pump holder
bracket around the thru bolt.
Screw the wing nut onto the thru bolt and twist to the right until the wing nut is secured.
OPERATION
Set-up: Horizontal wall mount
The nest accessory can be mounted on a wall or pegboard using the two through-holes in the back of
the accessory. Simply hang the nest on a wall near a sink and insert the FlexiPump unit. Then plug the
cord into an outlet. (Hardware not included.)
Set-up: on a wall
5
Mounting holes
FlexiPump™ Independent Flushing System User Manual
© Pure Processing, LLC. 2017. All rights reserved.
