PURE Jongo A2 - Rear panel controls and connectors

8
Rear panel controls and connectors
Line out Digital optical out
Digital coaxial out
R
L
5.5V DC
Jongo
A2
Mains
adapter
Connect to
mains power
supply
USB
USB connector
for optional USB
Ethernet adapter
Digital coaxial out
Connect to digital coaxial (S/PDIF)
input on an amplifier or receiver
Digital optical out
Connect to digital
optical (S/PDIF)
input on an amplifier
or receiver
Analogue audio
Connect to 3.5mm
input of any audio
product, or to
analogue inputs on
an amplifier, receiver,
TV or monitor
