PureLink PT-E-HD10 - Technical Specifications

User Manual
PT-E-HD10
4.Specications
Technical TX RX
Role of usage Transmitter [TX] Receiver [RX]
HDMI compliance HDMI Deep Color & full 3D
HDCP compliance Yes
Video bandwidth Single-link 225MHz [6.75Gbps]
Video support 480i / 480p / 720p / 1080i / 1080p60
HDMI over UTP Full HD: (1080p) ~40meter (130feet) (Cat.X)
HD: (720p/1080i) ~50meter (165feet) (Cat.X)
Audio support
Surround sound [up to 7.1ch] or stereo digital audio
Equalization
None 8 Level Digital Control
Input TMDS signal 1.2 Volts [peak-to-peak]
Input DDC signal 5 Volts [peak-to-peak, TTL]
ESD protection
−Human body model — ±19kV (air-gap discharge) & ±12kV (contact discharge)
−Core chipset — ±8kV
Input 1x HDMI/1x 3.5mm 1x RJ-45/1x 3.5mm
Output 1x RJ-45/1x 3.5mm 1x HDMI/1x 3.5mm
HDMI connector Type A [19-pin female]
RJ-45 connector WE/SS 8P8C(Reverse Mode)
3.5mm connector IR receiver / IR blaster IR receiver / IR blaster
Rotary Switch None Signal level equalization
Dimensions 75 x 90 x 25mm (L x W x H)
Weight 480g
Power Supply 5V 2A DC
Power Consumption 1 Watt (max)
Mechanical TX RX
Housing Metal enclosure
Dimensions
[L x D x H]
Model 75 x 91 x 27mm [2.9“ x 3.5“ x 1“] 75 x 91 x 27mm [2.9“ x 3.5“ x 1“]
Package 270 x 175 x 80mm [10.6" x 6.9" x 3.1"]
Carton 450 x 370 x 300mm [1'6" x 1'3" x 11.8"]
Weight
Model 239g [8.4oz] 239g [8.4oz]
Package 1000g [2.2 lbs]
Fixedness Wall-mounting case with screws
Power supply 5V 2A DC
Power consumption 1 Watt (max)
Operation temperature 32˚ ~ 104˚F (0˚ to 40˚C)
Storage temperature -4˚ ~ 140˚F (-20˚ ~ 60˚C)
Relative humidity 20~90% RH (no condensation)
4
