Purkeys DIRECT PLUS - Interior Light Installation with Severe Service

12
Step 1: Inside the nosebox, connect the severe service positive terminal to the
interior light input power terminal (see Figure 2) using a 10 gauge wire.
INTERIOR LIGHT INSTALLATION
WITH SEVERE SERVICE
Step 2: Terminate the Interior light positive wire with a #10 ring terminal and
connect to the Interior light input power (see Figure 2).
Step 3: Terminate the Interior light negative wire with a #10 ring terminal and
connect to Ground (see Figure 2).
Interior Light with Severe Service Installation Complete.
Severe service positive
Interior light input power
Ground
Figure 2
ese interior light instructions apply if you are installing the Purkeys severe
service kit (Direct Max only).
