LED STATUS LOGIC
No Source LED
Li Battery LED
Slow Flashing
Orange
Static State – No tractor
connected to the trailer and
the ligate batteries are less
than 12.4 volts.
Slow Flashing
Green on Li
Battery and
Source
O State – Source voltage
below 12.8 volts and extend
period is over. Voltage at
the li
batteries and the source is
above 12.4 volts.
Applies to all charging
sources.
Slow Flashing
Orange on Li
Battery and
Source
O State (Low Voltage)
– Li battery and source
voltage below 12.4 volts.
DC/DC converter
is o.
Applies to all charging
sources.
Rapid Flashing
Orange on Li
Battery and/or
Source
O State (Fault) – Voltage
between 2 and 8 volts.
Check fuses and wiring.
No LED
O State (Fault) – Open
circuit in li battery or
source circuit. is could
also be caused by
the ligate battery voltage
being below 6 volts, a
blown 2 amp fuse, or a bad/
tripped 30 amp fuse.
