PXM DMX DEMUX 8 User Manual

4
3. DESCRIPTION
Pin no.
1
2
13
14
6
5
4
3
15
16
17
18
7
8
9
10
11
12
19
20
21
22
23
24
Connection
GND (-)
GND (-)
GND (-)
GND (-)
OUT 1 (+)
OUT 2 (+)
OUT 3 (+)
OUT 4 (+)
OUT 5 (+)
OUT 6 (+)
OUT 7 (+)
OUT 8 (+)
DC + power type
DC + power type
DC + power type
DC - power type
DC - power type
DC - power type
DMX IN +
DMX IN -
DMX IN GND
DMX OUT +
DMX OUT -
DMX OUT GND
12-24V DC
