Pyle view PLDVD170 - Connections; Outlet Wires Connection

Outletwiresconnection
(supplied)
5
6
7
8
9
10
11
12
1YELLOWCABLE[VIDEO/AUDIO]:VIDEOOUT(YELLOW);
DIGITALAUDIOOUT(/)[Gotopage9]
2BLACKCABLE[AMPLIFIER:AUDIOOUT:Redright;Whiteleft[Gotopage9]
3
4
GREENCABLE[FRONTLEFTSPEAKER]:
GREENWITHWHITESTRIPE()
7GREYCABLE[
ORANGEYELLOW
]
PURPLECABLE:POWERANTENNA(Purple)
PURPLECABLE:AMPLIFIERTURNON(Purplewithwhitestripe)
5BROWNCABLE:POWERSCREEN
6GREEN(+);
FRONTRIGHTSPEAKER]:GREY(+)
GREYWITHWHITESTRIPE()
8BROWNCABLE[REARLEFTSPEAKER]:BROWN(+)
BROWNWITHWHITESTRIPE()
9BLUECABLE[REARRIGHTSPEAKER]:BLUE(+)
BLUEWITHWHITESTRIPE()
10REDCABLE[POWER]:12VOLT(+),ACCESSORY/SWITCHED
11BLACKCABLE[GROUND]:GROUND
12YELLOWCABLE:(+)12VOLT,CONSTANT
13BLACKBOX:EQUIPPEDWITHFUSEANDFILTER
14INSULATINGCOVER:SAMECOLORASTHECABLETERMINAL
-
-
-
-
ONOFF
8
Connections
1
23
4
13
13
