Connectingtoamonitorandspeakers,oraudiosystem
FMmodulator
oramplifier
TVorMonitor
VIDEOOUT
AUDIOOUT
Antennajack
Amplifierequippedwith
aDolbydigitaldecoder,or
aDTSdecoder,or
anMPEG2audiodecoder
75coaxialcableΩ
Frontspeaker
Frontspeaker
Centerspeaker
Rearspeaker
Rearspeaker
Subwoofer
Signalflow
Note:
1)Refertotheamplifiersownersmanual
andsettheFunctionsSetting(Audio,Digitalout)----Seepage23.
2)
3)
’’
WhenplayingDVDvideodiscsoraudioCDsencoded
viatheDTSrecording,pleaseusethecoaxialcable.
AndtheAudioSettingpleaserefertopage19.
Whenusingtheaudiocable,donotconnectthecoaxialcable
orspeakercable.
PowerAntenna
AmplifierTurnOn
PowerScreen
Frontspeaker
Green
Blue
Brown/White
Grey
Brown
Green/White
Grey/White
Blue/White
Filter/Fuse
Rearspeaker
Frontspeaker
Rearspeaker
Left
Right
12Volt(+),Accessory/Switched
Ground
+12Volt,constant
Remotesensorandremotecontroleyejack.
Connecttheremotecontroleyejacktothe
remotesensorunit.
PowerSupply
(Soldseparately)
