Pyle PT8000CH User Manual

ww w.PyleUSA.com
2
Read through this user manual before using the product to ensure
its correct use. Keep this manual for future reference.
The PT8000CH contains the excellent performance and reliability that PYLEUSA
products have been recognized for. The PT8000CH features the exibility needed
for demanding custom installation applications. It is ideal for use in home theater,
stereo, multi-room, multi-zone and commercial applications.
For best performance, please carefully read the instructions in this manual.
TABLE OF CONTENTS
Features
Front Panel Diagram
Rear Panel Diagram
System Design & Operation Considerations
System Design Examples
Diagram 4 - Multi Room Installation
Diagram 5 - Multi-Zone Installation #1
Diagram 6 - Multi-Zone Installation #2
Diagram 7- Home Theater/Multi-Room Installation
Installation Considerations
Installation
Operation
Troubleshooting
Specications
3
4
4
6
8
9
10
11
12
13
14
18
19
21

Pyle PT8000CH Specifications

General

Amplifier class	-
Peak power per channel	1000 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %
Speakers connectivity type	Banana connector
Purpose	Home
Product color	Black
Connectivity technology	Wired
Built-in display	Yes
Power protection features	Short circuit

Weight and Dimensions

Depth	490 mm
Width	483 mm
Height	180 mm
Weight	22000 g
