Pylontech Force-H2 User Manual

8/34
2.2.3 Control Module FC0500M-40 (internal power supply)
Control Module (FC0500-40) Display Panel
LED Button
Short Press
Display the LED panel for 20sec.
Long Press
(more than
5sec)
When status LED fast flashes blue ●, loss the button, then it is
115200 baud rate of RS485.
When status LED fast flashes orange ●, loss the button, then it
is 9600 baud rate of RS485.
Status
2 colors, Blue and orange
Refer to [LED Indicators Instructions]

Pylontech Force-H2 Specifications

General

Nominal Capacity	3.55 kWh
Battery Type	Lithium Iron Phosphate (LiFePO4)
Communication	CAN, RS485
Certification	CE, UN38.3, IEC62619
Warranty	10 years
Operating Temperature Range	-10°C to 50°C
Storage Temperature Range	-20°C to 60°C
IP Rating	IP20
Cycle Life	>6000 cycles
