Definition of RJ45 Port Pin
No.
CAN
RS485
RS232
1
---
---
---
2
GND
---
---
3
---
---
TX
4
CANH
---
---
5
CANL
---
---
6
---
---
RX
7
---
RS485A
---
8
---
RS485B
---
2.3 System Diagram
