Pylontech Force-H2 User Manual

34/34
☐
11
The first installation should do full charging progress
automatically.
If the status LED of BMS turns to blue, it means this
battery string is operation.
Annex 2: System Turn OFF Progress List
Tick after
completion
No.
Item
Remark
☐
1
Soft-off the inverter through inverter’s control panel.
Refer to chapter
3.5.4.
☐
2
Turn off the switch between inverter and this battery
string (Force-H2), or turn off the power switch of inverter,
to make sure no current through this battery string.
Refer to chapter
3.5.4.
☐
3
Turn off the “Power Switch” of the BMS.
Refer to chapter
3.5.4.

Pylontech Force-H2 Specifications

General

Nominal Capacity	3.55 kWh
Battery Type	Lithium Iron Phosphate (LiFePO4)
Communication	CAN, RS485
Certification	CE, UN38.3, IEC62619
Warranty	10 years
Operating Temperature Range	-10°C to 50°C
Storage Temperature Range	-20°C to 60°C
IP Rating	IP20
Cycle Life	>6000 cycles
