Pylontech Force-H2 User Manual

29/34
Warning: Single battery module is 35kg. If without handling tools must more than 2 men to
handling with it.
5.2.1.6 Pile up the new battery module. And pile up the battery modules and control module up
again.
5.2.1.7 Install back the control Module’s fix screw of left and right side. And Install back the fix
metal brackets.
5.2.1.8 Install back Grounding Cable, Communication Cable and the D+ and D- Power Cable.
5.2.1.9 Turn on this battery string. Refer to chapter 3.6.

Pylontech Force-H2 Specifications

General

Nominal Capacity	3.55 kWh
Battery Type	Lithium Iron Phosphate (LiFePO4)
Communication	CAN, RS485
Certification	CE, UN38.3, IEC62619
Warranty	10 years
Operating Temperature Range	-10°C to 50°C
Storage Temperature Range	-20°C to 60°C
IP Rating	IP20
Cycle Life	>6000 cycles
