TIMETRAX™ SYNC 7000/7000BDL110 MASTER CONTROL
Installation Instructions
Thank you for choosing a TimeTrax Sync™ 7000/7000BDL110 Master Clock System.
The TimeTrax Sync™ 7000/7000BDL110 synchronizes up to 200 TimeTrax Sync™ Analog
Clocks (part #5200) and/or Digital Clocks (part #DIG-4B, DIG-6B 41357G, 61357G).
The system can provide power to eight TimeTrax Sync™ Analog Clocks (part #5200) using
RJ45 connector. Digital Clocks need to have their own 100-240V AC 50/60Hz power
supplied.
The TimeTrax Sync™ 7000 integrates with 24V DC bells or horns and is able to operate a
bell/horn schedule up to 300 events.
The TimeTrax Sync™ 7000BDL110 includes a Relay SPDT contact for 110V AC bells and
horns. The 7000BDL110 provides contacts to bells and horns up to a total of 10amps @
125V AC. Please refer to page 15 for a complete list of bell and horns.
Analog or
Digital Clock
7000 master control
(BCD updates up to 200 clocks*)
DC Bells/Horns
or AC Relay Control
*Powers up to 8 analog clocks using RJ45 cable.
All other clocks must be supplied power.
