Tools
Screwdriver (Slotted, Phillips) Multimeter
Wrench Clip-on ammeter
Diagonal pliers Insulating tape
Thermometer Pliers
Anti-static wrist ring Clip Pliers
Tapes Strippers
Electrical interface settings:
If the battery is directly connected to the energy storage inverter or DC charger, please verify:
if the operating voltage, current, and power of the equipment align with the battery parameters listed
in "Table 1-1 Battery Pack Specifications".
Safety inspection:
Fire-fighting equipment such as portable dry powder fire extinguishers in proximity to the battery is
mandatory. Dangerous substances such as flammable or explosive materials must not be stored
near the battery.
When the battery arrives at the installation site, it must be unloaded and stored properly and
prevented from the direct sunshine and rain. Before installation, check if there is any component
missing according to 1.1 product standard configuration and check whether the box appearance is
intact;
Carefully handling the unpacking to preserve the insulation coating on the casing's surface.
Please contact PYTES if there is any damage or missing of products and / or components.
source and that the battery system is turned off. Distribution cabling needs to be handled carefully with
essential protective measures to avoid any safety hazards during the maintenance and operation.
The operation environment must comply with the requirements outlined in Chapter 3, "Operation
Environment." If not, necessary adjustments must be made and subsequently reevaluated.
The tools that may be used are shown in Table 5-1.
Table 5-1 Tools
5.2 Unpacking
5.1.2 Checking the operation environment
5.1.3 Tools
5.1.4 Technical preparation
The V series can be installed either vertically or horizontally. The instructions in this chapter are only for
horizontal installation, while vertical installation follows a similar process. All equipment must be placed
steadily after installation.
5.3.1 Install the battery
5.3 Installation
