1.2 BMS Functions
2 Interface and protection functions
2.1 Battery front panel schematic
Protection and Alarm Management and Monitor
Charge / Discharge End Cut-off Cells Balance
Charge over Voltage Protection Intelligent Charge
Charge / Discharge over Current Protection Charge/Discharge Current Limitation
Short Circuit Protection Administrator Monitoring
Power Cable Reverse Protection Log Record
High / Low Temperature Warning
Over / Under Temperature Protection
Remaining Power Calculation
Power Button
Ground
CAN/RS485 communication Port
DIP Switch
IoT Port Positive
Power Terminal
V5°
V5°α
Dry Contact
SOC Indicator
Alarm Indicator
Running Light
Start Switch
Negative
Power Terminal
8
To Next Page
