1 Specifications
Table 1-1 Battery Pack Specifications
Battery Model V5° V5°α
Power Terminal PHOENIX M6 Bolt Amphenol SurLok Plus 8.0mm
Chemistry LFP
Nominal Voltage 51.2V
Voltage Range 47.5V~57.6V
Nominal Capacity 100Ah
Nominal Energy 5.12kWh
L440mm*W530mm*H140mm(3.2U)
L17.32in*W20.87in*H5.51in(3.2U)
Unit Weight 44KG / 97lbs
Recommended Charge/
Discharge Current
Max Continuous Charge/
Discharge Current
Peak Charge/
Discharge Current
Round-Trip Efficiency ≥95%
Communication Protocol RS485, CAN, WiFi (W/ Optional Device)
Cycle Life ≥6000cycles
Calendar Life ≥10years
Within 1month: -20°C~50°C(-4℉~122℉)
1-3months: -10°C~40°C(14℉~104℉)
3-12months: 20°C~25°C(68℉~77℉)
75A
100A
101A~120A (3min);
121A~180A (15sec)
Charge: 0°C~45°C(32℉~113℉)
Discharge: -10°C~50°C(14℉~122℉)
Operating Temperature
UN38.3, CE, UL1973, UL9540A, UL9540, IEC62619, CEC, SGIPCertificates
Storage Temperature
Heating System
Temperature Rise 10°C(18℉)/Hour,
Operation Temperature -18°C~10°C(-0.4℉~50℉)
[1], [2]: The recommended and Max continuous charge and discharge current is for a battery cell temperature within
10°C~40°C(50℉~104℉)to consider. It will result in a derating on current if out of the temperature range.
[3]: Test conditions 0.2C Charging/Discharging, @25°C(77℉), 80% DOD.
[4]: Integrated with some inverters, heating system may consume enengy from battery when there's voltage difference among
system modules, between 0°C/32°F to 5°C/41°F. Follow 5.3.3 of this manual for multiple batteries power cable connection to
minimize influence of the circular current, thus decrease battery energy loss.
Unit Dimension
[3]
[2]
[1]
6
