www.qimaging.com ©2014 QImaging. All rights reserved. QI_OPTIMOS_UM_Rev_A0
21
optiMOS USER MANUAL
CHAPTER 5
SPECIFICATIONS
Camera Dimensions (Front)
A A
(0,0)
Camera Dimensions (Bottom)
4.93in
125.2mm
3.00in
76.2mm
BOTH SIDES
2.44in
61.9mm
BOTH SIDES
Additional Camera Measurements
Dimensions: 97.8 mm x 125.2 mm x 178.5 mm
Camera weight: 1.72 kg
Optical interface: 1”, C-mount optical format
Mounting hole thread size: 1/4”-20 thread
