b. Attach the screw that secures the PCIe bracket to the rear panel.
Full-height PCIe expansion card
Low-prole PCIe expansion card
Note
• The pan head M3x5 screw requires a Phillips #2 screwdriver.
• A torque of 5 kgf.cm (4.34 lbf.in) ± 0.5 kgf.cm (0.43 lbf.in) is recommended for
electric screwdrivers.
18. Attach the case cover.
a. Place the cover on the device.
| NAS Repair Manual
Category D NAS Models 133
