Note
The self-tapping M5x10 screws require a Phillips #2 screwdriver.
9. Attach the rear panel.
a. Align the holes on the rear panel to the screw holes and ports on the chassis.
b. Attach the screws that secure the rear panel to the chassis.
Note
• The at head M3x4 screws require a Phillips #2 screwdriver.
• Attach the screws securely in the following order to ensure a proper t and
prevent stress on the cover: bottom rst, then back panel, sides, and top edge
last.
| NAS Repair Manual
Category C NAS Models 86
