QNAP TS-212P User Manual

111
Chapter 10. Use the LCD Panel
This feature is only available for NAS models with LCD panels.
LCD Panel – QTS 4.3.0 and above
You can use the LCD panel to configure system settings and view system information. You
can use the “ENTER” and “SELECT” buttons next to the panel to navigate through the LCD
menu.
After starting the NAS, you can see its name and firmware version appear on the panel.
N
A
S
5
F
4
D
E
3
4
.
3
.
0
(
2
0
1
6
0
7
0
3
)
After a few seconds, the panel will be automatically turned off. Then you can begin to
configure settings or view system information.
Viewing system IP address
1. Press “ENTER” or “SELECT” to turn on the panel.
2. Press “SELECT” to browse the NAS model name and the available IP addresses (for
each network and thunderbolt interface).
This feature is particularly useful when the NAS is near you.
Viewing and configuring system settings
When the name and firmware version of the NAS appear on the panel, press “ENTER” for
two seconds to view the Main Menu, which will automatically disappear if no further actions
are performed in ten seconds.
There are eight options on the Main Menu:
1. TCP/IP
2. Physical disk
3. Volume
4. System
5. Shut down
6. Reboot
7. Password
8. Back

QNAP TS-212P Specifications

General

RAID levels	0, 1, JBOD
RAID support	Yes
Storage drive capacity	8 GB
Storage drive interface	Serial ATA II
Storage drives installed	No
Installed storage drive type	-
Supported storage drive types	HDD
Total installed storage capacity	0 TB
Maximum supported storage capacity	8 TB
Number of storage drives installed	0
Number of storage drives supported	2
Processor family	Marvell
Processor frequency	1.66 GHz
Flash memory	16 MB
Internal memory	512 GB
Internal memory type	DDR3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Product color	White
Type	NAS
Power consumption (sleep)	6 W
Power consumption (typical)	13 W

Weight and Dimensions

Depth	218.4 mm
Width	85 mm
Height	165.5 mm
Weight	910 g
Package weight	2200 g
