QNAP TS-230 User Manual

3. Installation and Configuration
This chapter provides specific hardware and firmware installation and configuration steps.
Hardware Installation
This section provides information on installing drives, memory modules, and expansion cards.
Drive Installation
The TS-230 is compatible with 3.5-inch and 2.5-inch SATA hard drives, and 2.5-inch solid-state drives.
Installing 3.5-inch Hard Drives on 3.5-inch Drive Trays
Warning
• Installing a drive and installing QTS deletes all data on the drive.
• Observe electrostatic discharge (ESD) procedures to avoid damage to components.
•
Moving fan blades: Keep your hands and other body parts away from moving fan
blades.
•
Other moving components: Keep your hands and other body parts away from other
moving components.
1. Power off the NAS.
2. Disconnect the power cord from the electrical outlet.
3. Disconnect all cables and external attachments.
4. Remove the case cover.
a. Lay the NAS on the left side.
b. Loosen the screw.
TS-230 User Guide
Installation and Configuration 11

QNAP TS-230 Specifications

General

Type	NAS
Noise level	15 dB
Device class	Home & Home Office
Share folder	AFP, CIFS/SMB, FTP
Backup features	Cloud, USB drive, iSCSI LUN
Backup function	Yes
Browser supported	Chrome, Firefox, Internet Explorer, Safari
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS
Video input channels	16 channels
RAID levels	0, 1, JBOD
Storage drive capacity	0 GB
Supported file systems	FAT32, HFS+, NTFS, exFAT, ext3, ext4
Storage drive interface	-
Storage drives installed	No
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	2
Supported storage drive interfaces	Serial ATA II, Serial ATA III
Cables included	AC, LAN (RJ-45)
Number of screws	14
Processor cores	4
Processor model	RTD1296
Processor family	Realtek
Processor frequency	1.4 GHz
Flash memory	4000 MB
Internal memory	2 GB
Internal memory type	DDR4
Operating system version	5.0.0
Operating system installed	QNAP QTS
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Chassis type	Tower
Cooling type	Active
Fan diameter	80 mm
Product color	Blue
LED indicators	HDD, LAN, Status, USB
Number of fans	1 fan(s)
Fan voltage	12 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply location	External
Power consumption (typical)	12.277 W
Power consumption (HDD standby)	4.48 W
Power supply unit (PSU) capacity	65 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	156.26 mm
Width	90.18 mm
Height	188.64 mm
Weight	1980 g
Package weight	2010 g
