QNAP TS-230 User Manual

Component TS-230
Drive compatibility 3.5-inch bays:
• 3.5-inch SATA hard disk drives
• 2.5-inch SATA hard disk drives
• 2.5-inch SATA solid-state drives
Important
2.5-inch drive trays only support drives with a maximum
height of 9.5 mm.
Hot-swapping Supported
Network
Gigabit Ethernet ports 1 x GbE RJ45
External I/O Ports & Expansion Slots
USB ports Front: 1 x USB 3.0 Type-A
Note
This USB port supports One Touch Copy.
Back:
• 1 x USB 2.0 Type-A
• 1 x USB 3.0 Type-A
Dimensions
Form factor Tower
Dimensions (H x W x D) 188.64 x 90.18 x 156.26 mm
(7.43 x 3.55 x 6.15 in)
Net weight 1.11 kg (2.45 lbs)
Others
Power supply unit 65W, AC 100 to 240 V, 50/60 Hz
Warning
To reduce the risk of fire or electric shock, ensure that
you only connect the power cord to a properly grounded
electrical outlet.
System battery CR2032 lithium battery (3V, 225 mAh)
Warning
To avoid potential battery explosion, causing injury or
damage to components, ensure that you replace the
existing battery with a battery of the same type.
Important
Dispose of used batteries according to local regulations
or the instructions of the battery manufacturer.
TS-230 User Guide
Product Overview 5

QNAP TS-230 Specifications

General

Type	NAS
Noise level	15 dB
Device class	Home & Home Office
Share folder	AFP, CIFS/SMB, FTP
Backup features	Cloud, USB drive, iSCSI LUN
Backup function	Yes
Browser supported	Chrome, Firefox, Internet Explorer, Safari
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS
Video input channels	16 channels
RAID levels	0, 1, JBOD
Storage drive capacity	0 GB
Supported file systems	FAT32, HFS+, NTFS, exFAT, ext3, ext4
Storage drive interface	-
Storage drives installed	No
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	2
Supported storage drive interfaces	Serial ATA II, Serial ATA III
Cables included	AC, LAN (RJ-45)
Number of screws	14
Processor cores	4
Processor model	RTD1296
Processor family	Realtek
Processor frequency	1.4 GHz
Flash memory	4000 MB
Internal memory	2 GB
Internal memory type	DDR4
Operating system version	5.0.0
Operating system installed	QNAP QTS
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Chassis type	Tower
Cooling type	Active
Fan diameter	80 mm
Product color	Blue
LED indicators	HDD, LAN, Status, USB
Number of fans	1 fan(s)
Fan voltage	12 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply location	External
Power consumption (typical)	12.277 W
Power consumption (HDD standby)	4.48 W
Power supply unit (PSU) capacity	65 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	156.26 mm
Width	90.18 mm
Height	188.64 mm
Weight	1980 g
Package weight	2010 g
