Page #11 background imageLoading...
Page #11 background image
Item Quantity
Power cord 1
Ethernet cable TS-431KX: 2 x Cat5e
TS-431X3: 1 x Cat5e
Screws for 3.5-inch drives 16
Screws for 2.5-inch drives 12
Quick Installation Guide (QIG) 1
Safety Information
The following instructions help ensure personal safety and environmental safety. Read these instructions
carefully before performing any operations.
General Instructions
The NAS should be stored in a secure location with restricted access, controlled through the use of a
tool, lock and key, or any means of security.
Only qualified, skilled, and authorized persons with knowledge of all restrictions, safety precautions,
and installation and maintenance procedures should have physical access to the NAS.
To avoid potential injury or damage to components, ensure that the drives and other internal system
components have cooled before touching them.
Observe electrostatic discharge (ESD) procedures to avoid potential injury or damage to components.
Power
To reduce the risk of fire or electric shock, ensure that you only connect the power cord to a properly
grounded electrical outlet.
Devices with redundant power supply may have one or more power supply unit (PSU) cords. To avoid
serious injuries, a trained service technician must disconnect all PSU cords from the device before
installing or replacing system components.
System Battery
To avoid potential battery explosion, causing injury or damage to components, ensure that you replace
the existing battery with a battery of the same type.
Dispose of used batteries properly according to local regulations or the instructions of the battery
manufacturer.
Moving Parts
Moving fan blades: Keep your body parts away from moving fan blades while the device is connected
to a power source.
TS-431KX/TS-431X3 User Guide
Product Overview 10

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the QNAP TS-431KX and is the answer not in the manual?

QNAP TS-431KX Specifications

General IconGeneral
RAID levels0, 1, 5, 6, 10, JBOD
Storage drive size- \
Storage drive capacity- GB
Supported file systemsFAT32, HFS+, NTFS, ext3, ext4
Storage drive interfaceSerial ATA III
Storage drives installedYes
Installed storage drive typeHDD
Storage drive sizes supported2.5, 3.5 \
Supported storage drive typesHDD & SSD
Total installed storage capacity32 TB
Number of storage drives installed-
Number of storage drives supported4
Supported storage drive interfacesSerial ATA II, Serial ATA III
Chassis typeTower
Cooling typeActive
Fan diameter120 mm
Product colorBlack
LED indicatorsHDD, LAN, Power, SSD, Status
Number of fans1 fan(s)
Cable lock slot typeKensington
TypeNAS
Noise level19.5 dB
Device classSmall & Medium Business
Backup featuresCloud, USB drive, iSCSI LUN
Browser supportedApple Safari 7+, Google Chrome, Microsoft Internet Explorer 10+, Mozilla Firefox
Security algorithms256-bit AES, FIPS 140-2, HTTPS, SNMP, SSH
Processor modelAlpine AL-314
Processor frequency1.7 GHz
Processor manufacturerAnnapurna Labs
Operating system version4.4.2
Operating system installedQNAP Turbo System
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina
Linux operating systems supportedCentOS 7.0, Ubuntu 14.04
Server operating systems supportedWindows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Flash memory512 MB
Memory slots1
Internal memory2 GB
Memory clock speed1600 MHz
Memory form factorSO-DIMM
Internal memory typeDDR3
Maximum RAM supported8 GB
Fan voltage12 V
AC input voltage100 - 240 V
Power supply locationExternal
Power consumption (sleep)11.65 W
Power consumption (typical)26.7 W
Power supply unit (PSU) capacity90 W
Ethernet LAN data rates10, 100, 1000, 10000 Mbit/s
Ethernet LAN data rate supported (max)10000 Mbit/s
Fiber optic connectorSFP+
USB 2.0 ports quantity0
Ethernet LAN (RJ-45) ports2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Cables includedAC, LAN (RJ-45)
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95 %
Harmonized System (HS) code84714100
Weight and Dimensions IconWeight and Dimensions
Depth219 mm
Width160 mm
Height169 mm
