3. Installation and Configuration
This chapter provides specific hardware and firmware installation and configuration steps.
Hardware Installation
This section provides information on installing drives, memory modules, and expansion cards.
Installing Drives
The TS-431X2 is compatible with 3.5-inch and 2.5-inch hard drives, and solid state drives. All four drive bays
support SSD cache acceleration.
Installing 3.5-inch Hard Drives
Warning
• Installing a drive deletes all data on the drive.
• Observe electrostatic discharge (ESD) procedures to avoid damage to components.
1. Power off the NAS.
2. Remove drive tray.
a. Pull the tray handle forward.
b. Pull the tray out.
3. Install a drive on the tray.
a. Place the drive so that the SATA connector is exposed.
b. Attach the screws to lock the drive to the tray.
TS-431X2 User Guide
Installation and Configuration 10
