QNAP TS-453mini User Manual

115
System Message Description
Sys. Fan Failed The system fan has failed.
Sys. Overheat The system has overheated.
HDD Overheat A hard drive has overheated.
CPU Overheat The CPU has overheated.
Network Lost Both LAN 1 and LAN 2 are disconnected in failover or load balancing mode.
LAN1 Lost LAN 1 is disconnected.
LAN2 Lost LAN 2 is disconnected.
HDD Failure A hard drive has failed.
Vol1 Full The disk volume (1) is full.
NAS HDD Ejected A hard drive has been ejected from the NAS.
RX#3 HDD Ejected A hard drive has been ejected from the expansion unit 3.
M.2 SSD Ejected A M.2 SSD has been ejected and may be defective as hot-plugging is not
supported for M.2 drives.
PCIe SSD Ejected A PCIe SSD has been ejected and may be defective as hot-plugging is not
supported for PCIe devices.
Vol1 Degraded The disk volume (1) is in degraded mode.
Vol1 Unmounted The disk volume (1) is unmounted.
Vol1 Nonactivate The disk volume (1) is inactive.
System startup
S
Y
S
T
E
M
B
O
O
T
I
N
G
>
>
>
There are several phases in the system startup process:
- System Booting: BIOS and hardware initialization, and system booting (no actions
need to be performed)

QNAP TS-453mini Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
RAID support	Yes
Storage drive size	2.5/3.5 \
Storage drive capacity	0 GB
Storage drive interface	Serial ATA III
Storage drives installed	No
Installed storage drive type	-
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	0
Number of storage drives supported	4
Processor family	Intel® Celeron®
Processor frequency	2 GHz
Flash memory	512 MB
Memory slots	2
Internal memory	2 GB
Internal memory type	DDR3L
Maximum RAM supported	8 GB
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Cooling type	Active
Product color	Black
Number of fans	1 fan(s)
Type	NAS
Operating system version	4.1.2
Operating system installed	QNAP Turbo System
AC input voltage	100-240 V
Power supply location	Built-in
Power consumption (sleep)	1.04 W
Power consumption (typical)	30.23 W
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	5 - 95 %
Cables included	AC, LAN (RJ-45)

Weight and Dimensions

Depth	200 mm
Width	151 mm
Height	210 mm
Weight	2000 g
Package weight	3400 g
